Deep Reactive Ion Etching (DRIE)

Deep Reactive Ion etching of Silicon (DRIE), or Deep Silicon Etching (DSiE), is a highly anisotropic etch process used to create deep, steep-sided holes and trenches in wafers/substrates, typically with high aspect ratios.

The Estrelas® DSiE system offers ultimate process flexibility, serving multiple process solutions across the Micro Electro Mechanical Systems (MEMS), Advanced Packaging and Nanotechnology markets.


DSiE Processes

The two technologies used to achieve deep etches in the fabrication of micro-electro-mechanical systems (MEMS) are the Bosch and the Cryogenic Processes. System and process development over many years has allowed the techniques to advance but the fundamental aspects of each remain the same:

  • Bosch process enables high etch rates, selectivity and anisotropy, and is typically used for features >1µm and depths >10µm​
  • Cryogenic Deep Silicon Etch (Cryo-DSiE) is typically used for smooth sidewalls and/or nano-etching or tapered profiles in applications such as micro moulds etc.
  • Mixed processes are an option for shallow, low aspect fine features.

Process Benefits

Designed to enable the fabrication of all Si etch devices​, Deep Silicon Etching delivers:

  • Process Flexibility​
  • High etch rates​
  • High selectivity to photoresist (PR) and oxide​
  • High Aspect-ratio​
  • Smooth sidewalls​
  • Minimised mask undercut​
  • SOI capability​
  • Si thinning & high Si exposed​
  • Capable SiO2 etch
Request More Information Download Brochure

Bosch Process

Bosch deep Si etching

Typical applications include MEMS, Microfluidics and Medical

The Bosch process uses a fluorine based plasma chemistry to etch the silicon, combined with a fluorocarbon plasma process to provide sidewall passivation and improved selectivity to etch mask. A complete etch process cycles between etch and deposition steps many times to achieve deep, vertical etch profiles. It relies on the source gases being broken down in a high-density plasma region before reaching the wafer.

This technique cannot be performed in reactive ion etch systems (RIE), as these have the wrong balance of ions to free radical species. This balance can be achieved in high-density plasma systems (HDP). The most widely used form of HDP uses inductive coupling to generate the high-density plasma region so is known as ‘inductively coupled plasma’ (ICP).


DSiE Bosch Process Stages

Deep Silicon Etch Bosch process
High rate, controlled scallops e.g. Microfluidics (200mm depth), vias (> 400 mm depth)

High rate, controlled scallops e.g. Microfluidics (200mm depth), vias (> 400 mm depth)

Deep Silicon Etch Bosch process

Microneedles created using the Bosch process ​

Cryo Process



DSiE Cryo Process

Typical applications include MEMS, Photonics and Biomedical

Just as for the Bosch process, this technique also uses SF6 to provide fluorine radicals for silicon etching. The silicon is removed in the form of SiF4, which is volatile.

The main difference is in the mechanism of sidewall passivation and mask protection. Rather than using a fluorocarbon polymer, this process relies on forming a blocking layer of oxide/fluoride (SiOxFy) on the sidewalls (around 10-20nm thick), this forms at the cryogenic temperatures used and the layer inhibits the attack on the underlying Si layer by the fluorine radicals.

The low temperature and low bias operation also assists in reducing the etch rate of the mask material, which is normally either photoresist or silicon dioxide.


Micro-mould created using the Cryo process

Micro-mould created using the Cryo process

Si waveguide etch

Si waveguide etch

Smooth sidewall cryogenic DSE (no scallops). Courtesy TU Twente

Smooth sidewall cryogenic DSE (no scallops).
Courtesy TU Twente

PlasmaPro 100 Estrelas DSiE

PROCESS FLEXIBILITY | PLASMA

PlasmaPro 100 Estrelas provides total flexibility for Deep Silicon Etch (DSiE) applications which is applied across across the Micro Electro Mechanical Systems (MEMS), Advanced Packaging and Nanotechnology markets.

  • Mechanical or electrostatic clamping
  • Improved reproducibility
  • High aspect ratio processes
  • Increased mean time between cleans (MTBC)
Request Quote
Download Brochure
PlasmaPro 100 Estrelas Cluster for Deep Silicon Etch
